HPE Networking Comware Switch Chassis 12902E

HPE Networking Comware Switch Chassis 12902E, Managed, L3, Power over Ethernet (PoE), Rack mounting, 1U

Reasons To Buy

Modern, Scalable and Distributed Architecture

The HPE Networking Comware Switch Series 12900E provides non-blocking, lossless Clos architecture with VOQs and large buffers with the flexibility and scalability for future growth.
Distributed architecture with separation of data and control planes delivers enhanced fault tolerance and facilitates continuous operation and zero service disruption during planned or unplanned control-plane events.
To meet the demands of next-generation networks, a new generation of OS-Comware v9 has been introduced that provides rich new features built on a modular and open architecture, supports containerized deployment and can run third-party software applications.
In-Service Software Upgrade (ISSU) provides an upgrade of the entire chassis, or an individual task or process, with zero packet loss.
It provides 2x scalability with H2 modules at the same price per port of HB modules

High-Performance Switch Series with Broad Interface Options

The HPE Networking Comware Switch Series 12900E provides the Layer 2 and Layer 3 fabrics which are flexible, resilient, and scalable with VXLAN support and sub-second convergence times.
High-density 1GbE, 10GbE, 40GbE,100GbE and 400GbE interface connectivity with up to 16 interface module slots scales up to 768 1GbE/10GbE/40GbE ports, 576 100GbE ports and 192 400GbE ports.
It delivers up to 184 Tbps (bi-directional) switching capacity and 92.1 Bpps throughput with nonblocking wirespeed performance and up to six fabric modules for a distributed scalable fabric architecture.

Optimized for the Next-Generation Data Center

The HPE Networking Comware Switch Series 12900E provides the Layer 2 fabrics which are flexible, resilient, and scalable with VXLAN, TRILL and/or HPE Intelligent Resilient Fabric (IRF).
Type X modules that offer automation capabilities with HPE Intelligent Management Center (IMC) Orchestrator and Analyzer, streaming telemetry support with Precision Timing Protocol (PTP) and up to 16K multicast group support.
Enhanced HPE Multitenant Device Context (MDC) for multi-tenancy gives the ability to virtualize a physical switch into multiple logical device.
Network and storage convergence with support for Fibre Channel over Ethernet (FCoE) and Data Center Bridging (DCB) protocols includes IEEE 802.1Qaz Data Center Bridging Exchange (DCBX), Enhanced Transmission Selection (ETS), and IEEE 802.1Qbb Priority Flow Control (PFC).

Enterprise-Class Availability and Resiliency with Broad Layer 2 and Layers 3 Feature Set

The Intelligent Resilient Fabric (IRF) creates virtual resilient switching fabrics where two HPE Networking Comware Switch Series 12900E perform as a single Layer 2 switch and Layer 3 router that can be attached using standard LACP for automatic load balancing and high availability.
This switch series offers hot-swappable modules and redundant load-sharing fabrics, management, power and high-speed fan assemblies which provides you with optimum network performance and availability while simplifying your network operations.
Comprehensive switching, routing and service provider feature set with full IPv4/IPv6, ACLs, QoS, MPLS/VPLS and multicast capabilities is offered.

Description

HPE Networking Comware Switch Chassis 12902E. Switch type: Managed, Switch layer: L3. Console port: RS-232. MAC address table: 16384 entries, Switching capacity: 19200 Gbit/s. DC input voltage: 48 - 60 V. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Specifications

Management features
Switch layer	L3
Switch type	Managed
Ports & interfaces
Console port	RS-232
Number of management ports	2 pc(s)
Network
10G support	Yes
Data transmission
MAC address table	16384 entries
Switching capacity	19200 Gbit/s
Throughput	11500 Mpps
Protocols
Routing protocols	BGP4, IS-IS, MPLS, OSPF, OSPFv3, RIP, RIPng
Design
Rack mounting	Yes
Stackable	No
Product colour	Gray, Black
Form factor	1U
Performance
Processor frequency	1000 MHz
Memory type	DDR3-SDRAM
Internal memory	8000 MB
Flash memory	1024 MB
Built-in processor	Yes
Stackable	No
Power
Power supply included	No
AC input voltage	100 - 240 V
DC input voltage	48 - 60 V
Power consumption note	1800W
Power source	AC/DC
Power supply note	16 power supply slots 1 minimum power supply required (ordered separately)
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Other features
Latency	< 5 microseconds (64-byte packets)
Performance management	IMC - Intelligent Management Center; Command-line interface; Out-of-band management (serial RS-232C); SNMP manager; Telnet; Terminal interface (serial RS-232C); Modem interface; IEEE 802.3 Ethernet MIB; Ethernet interface MIB
Memory and processor	Quad Core MIPS64 @ 1 GHz, 1 GB flash, 8 GB DDR3 SDRAM
Weight (imperial)	52.91 lbs
I/O ports	(2) I/O module slots; Supports a maximum of 96 100 GbE, 40Gbe or 1/10 GbE ports, or 48 1/10 GBASE-T ports, or a combination
Weight & dimensions
Width	17.3" (440 mm)
Depth	35.2" (895 mm)
Height	5.24" (133 mm)
Weight	52.9 lbs (24 kg)
