HPE Aruba Networking AP-585EX (RW) Dual Radio 4x4 802.11ax Internal Omni Ants Unified HazLoc AP

HPE Aruba Networking AP-585EX (RW) Dual Radio 4x4 802.11ax Internal Omni Ants Unified HazLoc AP, 2.4 GHz, 5 GHz, 2970 Mbit/s, WPA2, WPA3, 1000,5000 Mbit/s

Reasons To Buy

High Performance Ruggedized Outdoor Wi-Fi 6 APs

HPE Aruba Networking 580EX Series Hazardous Location Access Points are designed for hazardous environments, including outdoor oil rigs, industrial manufacturing, and transportation sites and provide a peak aggregate data rate of 2.97 Gbps.
The AP includes options for 5G Ethernet, SFP+, and PSE out for flexible connectivity.
It improves efficiency and security with Wi-Fi 6 capabilities including MU-MIMO, OFDMA, WPA3, and Enhanced Open.
Dual redundant power/port failover and support for AC provide high availability with uninterrupted performance.
Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the AP where it receives a strong radio signal.

Weatherproof and Temperature Hardened

HPE Aruba Networking 580EX Series Hazardous Location Access Points meet the needs of hazardous locations with Class 1, Division 2, and ATEX Zone 2 certifications like outdoor oil rigs, industrial manufacturing, and transportation sites.
The APs are ruggedized and tested for -40°C to +65°C, including full sun deployments.
The 580EX series is IP66/67 rated with industrial surge protection.
The APs can withstand extreme temperatures, persistent moisture, precipitation, and are fully sealed to keep out airborne contaminants.

Industrial IoT Ready

HPE Aruba Networking 580EX Series Hazardous Location Access Points can serve as IoT platforms that bolster network security and provide coverage for a range of IoT devices without the need for network overlays and include integrated, high-power antennas for increased performance and coverage.
The AP provides high-power Bluetooth and 802.15.4/Zigbee radios for increased IoT coverage.
Target wake time (TWT) improves battery life of IoT devices.
Intelligent power monitoring (IPM) feature provides the ability to enable or disable capabilities based on available Power over Ethernet (PoE) power.
HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.

Enhanced Security

The HPE Aruba Networking 580EX Series Hazardous Location Access Points offer enhanced security with dynamic segmentation to remove time-consuming, error-prone tasks of managing complex and static VLANs, ACLs and subnets by dynamically assigning policies and keeping traffic protected and separated.
The AP offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls (PEF).
It simplifies policy enforcement by using the PEF to encapsulate traffic from the AP to the gateway (or mobility controller) for end-to-end encryption and inspection.
For enhanced device assurance, the HPE Aruba Networking 580EX Series Hazardous Location Access Points include an installed trusted platform module (TPM) for protected storage of credentials, keys, and boot code.

Description

HPE Aruba Networking AP-585EX (RW) Dual Radio 4x4 802.11ax Internal Omni Ants Unified HazLoc AP. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2970 Mbit/s. Security algorithms: WPA2, WPA3. Ethernet LAN data rates: 1000,5000 Mbit/s. Power over Ethernet (PoE). Product color: White

Specifications

Performance
Maximum data transfer rate	2970 Mbit/s
Ethernet LAN data rates	1000,5000 Mbit/s
Spread spectrum method	DSSS, OFDM, OFDMA
2.4 GHz	Yes
5 GHz	Yes
Frequency band	20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), peak data rate 2.97 Gbps, maximum data rate 3.55 Gbps
Number of users	1024 user(s)
Networking standards	IEEE 802.11ax, IEEE 802.11mc
Certification	Wi‐Fi Alliance Bluetooth SIG Ethernet Alliance (E0, PoE PD device, Class 6; E2, PoE PSE device, Class 3) Class 1 Div 2 ATEX Zone 2 IECEx
MIMO type	Multi User MIMO
MIMO	Yes
Compatible operating systems	HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8 HPE Aruba Networking Operating System 10
Features
6 GHz	No
Maximum data transfer rate	2970 Mbit/s
Ethernet LAN data rates	1000,5000 Mbit/s
Spread spectrum method	DSSS, OFDM, OFDMA
2.4 GHz	Yes
5 GHz	Yes
Frequency band	20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), peak data rate 2.97 Gbps, maximum data rate 3.55 Gbps
Number of users	1024 user(s)
Networking standards	IEEE 802.11ax, IEEE 802.11mc
Bluetooth	Yes
Bluetooth version	5.0
MIMO type	Multi User MIMO
MIMO	Yes
MACsec support	No
Compatible operating systems	HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8 HPE Aruba Networking Operating System 10
Security
Security algorithms	WPA2, WPA3
Management features
Access point management	On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Ports & interfaces
USB connector type	USB Type-C
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Power
Power consumption (typical)	71 W
Output voltage	110 - 240 V
Power over Ethernet (PoE)	Yes
Design
Placement	Ceiling, Pole, Wall
International Protection (IP) code	IP66
Product colour	White
Certification	Wi‐Fi Alliance Bluetooth SIG Ethernet Alliance (E0, PoE PD device, Class 6; E2, PoE PSE device, Class 3) Class 1 Div 2 ATEX Zone 2 IECEx
Recommended usage	Outdoor
Antenna
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	5.8 dBi
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Technical details
Compliance certificates	Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Certificates
Certification	Wi‐Fi Alliance Bluetooth SIG Ethernet Alliance (E0, PoE PD device, Class 6; E2, PoE PSE device, Class 3) Class 1 Div 2 ATEX Zone 2 IECEx
Compliance certificates	Federal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Weight & dimensions
Width	12.8" (324 mm)
Depth	12.3" (313 mm)
Height	12.6" (320 mm)
Weight	11.6 lbs (5.24 kg)
Package width	17" (431 mm)
Package depth	16.3" (415 mm)
Package height	17.4" (442 mm)
Package weight	17.2 lbs (7.81 kg)
Packaging data
Package width	17" (431 mm)
Package depth	16.3" (415 mm)
Package height	17.4" (442 mm)
Package weight	17.2 lbs (7.81 kg)
Other features
I/O ports	Ethernet wired port (RJ-45) Ethernet wired port (RJ-45) PSE Ethernet wired port (SFP+) USB-C console interface
Weight (imperial)	11.5 lbs
Operational conditions
Operating relative humidity (H-H)	5 - 93%
Operating temperature (T-T)	-40 - 65 °C
Storage temperature (T-T)	-40 - 70 °C
Operating altitude	0 - 118110.2" (0 - 3000 m)
System requirements
Compatible operating systems	HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8 HPE Aruba Networking Operating System 10
