HPE Aruba Networking Aruba ClearPass C3010 server 3.6 TB Rack (1U) Intel® Xeon® Gold 5118 2.3 GHz 64 GB DDR4-SDRAM 500 W

Aruba ClearPass C3010 Appliance

Description

The Aruba ClearPass Policy Manager, part of the Aruba 360 Secure Fabric, provides role- and device-based secure network access control for IoT, BYOD, corporate devices, as well as employees, contractors and guests across any multivendor wired, wireless and VPN infrastructure.

With a built-in context-based policy engine, RADIUS, TACACS+, non-RADIUS enforcement using OnConnect, device profiling, posture assessment, onboarding, and guest access options, ClearPass is unrivaled as a foundation for network security for organizations of any size.

For comprehensive integrated security coverage and response using firewalls, EMM/MDM and other existing solutions, ClearPass supports the Aruba 360 Security Exchange Program. This allows for automated threat detection and response workflows that integrate with third- party security vendors and IT systems previously requiring manual IT intervention.

In addition, ClearPass supports secure self-service capabilities, making it easier for end users trying to access the network. Users can securely configure their own devices for enterprise use or Internet access based on admin policy controls. Aruba wireless customers in particular can take advantage of unique integration capabilities such as AirGroup, as well as ClearPass Auto Sign-On (ASO). ASO enables a user's network authentication to pass automatically to their enterprise mobile apps so they can get right to work.

The result is detailed visibility of all wired and wireless devices connecting to the enterprise, increased control through simplified and automated authentication or authorization of devices, and faster, better incident analysis and response through the integration of
Aruba IntroSpect UEBA and third-party partner ecosystems. This is achieved with a comprehensive and scalable policy management platform that goes beyond traditional AAA solutions to deliver extensive enforcement capabilities for IT-owned and BYOD security requirements.

Specifications

Processor
Processor generation	1st Generation Intel® Xeon® Scalable
Processor frequency	2.3 GHz
Processor family	Intel® Xeon® Gold
Processor model	5118
Processor cores	12
Number of processors installed	1
Thermal Design Power (TDP)	105 W
Tcase	81 °C
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Stepping	M0
Scalability	4S
Processor threads	24
Processor package size	76.0 x 56.5 mm
Processor operating modes	64-bit
Processor lithography	14 nm
Processor codename	Skylake
Processor code	SR3GF
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Maximum number of PCI Express lanes	48
Maximum internal memory supported by processor	768 GB
Execute Disable Bit	Yes
Embedded options available	Yes
Processor cache type	L3
Processor cache	16.5 MB
Conflict-Free processor	Yes
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor boost frequency	3.2 GHz
Memory
Internal memory	64 GB
Maximum internal memory	768 GB
Internal memory type	DDR4-SDRAM
Memory slots	24x DIMM
Storage
Total storage capacity	3.6 TB
Number of HDDs installed	6
HDD speed	10000 RPM
HDD capacity	600 GB
HDD interface	Serial Attached SCSI (SAS)
RAID support	Yes
RAID levels	10
Optical drive type	No
Maximum storage capacity	3.6 TB
Hot-Plug support	Yes
Network
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ports & interfaces
VGA (D-Sub) ports quantity	1
Serial ports quantity	1
Ethernet LAN (RJ-45) ports	4
Expansion slots
PCI Express slots version	3.0
Design
Chassis type	Rack (1U)
Rack mounting	Yes
Optical drive type	No
Performance
Remote administration	iLO
Harmonized System (HS) code	84714100
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Turbo Boost Technology	2.0
Intel TSX-NI	Yes
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel TSX-NI version	1.00
Processor ARK ID	120473
Enhanced Intel SpeedStep Technology	Yes
Power
Redundant power supply (RPS) support	Yes
Power supply input frequency	50/60 Hz
Power supply	500 W
Technical details
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Logistics data
Harmonized System (HS) code	84714100
Weight & dimensions
Width	17.1" (434.3 mm)
Weight	35.9 lbs (16.3 kg)
Height	1.7" (43.2 mm)
Depth	27.8" (707 mm)
